BAWH56WT1G
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- Description70V ANODE DIODE
- CategoryDiodes - Rectifiers - Single
-
ECAD Model
- Share
In Stock: 113
Can ship immediately
Pricing:
- 1$0.06237
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Active
- Diode Type:Standard
- Voltage - DC Reverse (Vr) (Max):70 V
- Current - Average Rectified (Io):200mA (DC)
- Voltage - Forward (Vf) (Max) @ If:1.25 V @ 150 mA
- Speed:Small Signal =< 200mA (Io), Any Speed
- Reverse Recovery Time (trr):6 ns
- Current - Reverse Leakage @ Vr:2.5 µA @ 70 V
- Capacitance @ Vr, F:2pF @ 0V, 1MHz
- Mounting Type:Surface Mount
- Package / Case:SC-70, SOT-323
- Supplier Device Package:SC-70 (SOT323)
- Operating Temperature - Junction:-55°C ~ 175°C
