ESH1B M2G

Technical Details

• Series:-
• Package:Tape & Reel (TR)
• Part Status:Active
• Diode Type:Standard
• Voltage - DC Reverse (Vr) (Max):100 V
• Current - Average Rectified (Io):1A
• Voltage - Forward (Vf) (Max) @ If:900 mV @ 1 A
• Speed:Fast Recovery =< 500ns, > 200mA (Io)

• Reverse Recovery Time (trr):15 ns
• Current - Reverse Leakage @ Vr:1 µA @ 100 V
• Capacitance @ Vr, F:16pF @ 4V, 1MHz
• Mounting Type:Surface Mount
• Package / Case:DO-214AC, SMA
• Supplier Device Package:DO-214AC (SMA)
• Operating Temperature - Junction:-55°C ~ 175°C
