ACDBN120-HF
Comchip Technology
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE SCHOTTKY 20V 1A 1206
- CategoryDiodes - Rectifiers - Single
- Datasheet ACDBN120-HF Datasheet
-
ECAD Model
- Share
In Stock: 169
Can ship immediately
Pricing:
- 1$0.5
- 3,000$0.088
- 6,000$0.0792
- 15,000$0.0704
- 30,000$0.066
- 75,000$0.0616
Quote It
Technical Details
- Series:Automotive, AEC-Q101
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- Diode Type:Schottky
- Voltage - DC Reverse (Vr) (Max):20 V
- Current - Average Rectified (Io):1A
- Voltage - Forward (Vf) (Max) @ If:320 mV @ 100 mA
- Speed:Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr):-
- Current - Reverse Leakage @ Vr:200 µA @ 20 V
- Capacitance @ Vr, F:110pF @ 4V, 1MHz
- Mounting Type:Surface Mount
- Package / Case:2-SMD
- Supplier Device Package:1206
- Operating Temperature - Junction:-55°C ~ 125°C
