VS-MBRB735TRL-M3

Technical Details

• Series:-
• Package:Tube
• Part Status:Active
• Diode Type:Schottky
• Voltage - DC Reverse (Vr) (Max):35 V
• Current - Average Rectified (Io):7.5A
• Voltage - Forward (Vf) (Max) @ If:570 mV @ 7.5 A
• Speed:Fast Recovery =< 500ns, > 200mA (Io)

• Reverse Recovery Time (trr):-
• Current - Reverse Leakage @ Vr:100 µA @ 35 V
• Capacitance @ Vr, F:400pF @ 5V, 1MHz
• Mounting Type:Surface Mount
• Package / Case:TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
• Supplier Device Package:TO-263 (D2Pak)
• Operating Temperature - Junction:-65°C ~ 150°C
