VS-12TQ040SHM3
Vishay General Semiconductor – Diodes Division
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE SCHOTTKY 40V 15A D2PAK
- CategoryDiodes - Rectifiers - Single
- Datasheet VS-12TQ040SHM3 Datasheet
-
ECAD Model
- Share
In Stock: 124
Can ship immediately
Pricing:
- 1$0.94555
- 1,000$0.89029
Quote It
Technical Details
- Series:Automotive, AEC-Q101
- Package:Tape & Reel (TR)
- Part Status:Active
- Diode Type:Schottky
- Voltage - DC Reverse (Vr) (Max):40 V
- Current - Average Rectified (Io):15A
- Voltage - Forward (Vf) (Max) @ If:560 mV @ 15 A
- Speed:Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr):-
- Current - Reverse Leakage @ Vr:1.75 mA @ 40 V
- Capacitance @ Vr, F:900pF @ 5V, 1MHz
- Mounting Type:Surface Mount
- Package / Case:TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Supplier Device Package:D2PAK
- Operating Temperature - Junction:-55°C ~ 150°C
