VS-STPS20L15GL-M3
Vishay General Semiconductor – Diodes Division
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE SCHOTTKY 15V 20A TO263AB
- CategoryDiodes - Rectifiers - Single
- Datasheet VS-STPS20L15GL-M3 Datasheet
-
ECAD Model
- Share
In Stock: 148
Can ship immediately
Pricing:
- 1$1.00279
- 800$0.97309
Quote It
Technical Details
- Series:Automotive, AEC-Q101
- Package:Tube
- Part Status:Active
- Diode Type:Schottky
- Voltage - DC Reverse (Vr) (Max):15 V
- Current - Average Rectified (Io):20A
- Voltage - Forward (Vf) (Max) @ If:410 mV @ 19 A
- Speed:Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr):-
- Current - Reverse Leakage @ Vr:10 mA @ 15 V
- Capacitance @ Vr, F:2000pF @ 5V, 1MHz
- Mounting Type:Surface Mount
- Package / Case:TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Supplier Device Package:TO-263 (D2Pak)
- Operating Temperature - Junction:-40°C ~ 150°C
