DNA30EM2200PZ-TUB

Technical Details

• Series:-
• Package:Tube
• Part Status:Active
• Diode Type:Standard
• Voltage - DC Reverse (Vr) (Max):2200 V
• Current - Average Rectified (Io):30A
• Voltage - Forward (Vf) (Max) @ If:1.26 V @ 30 A
• Speed:Standard Recovery >500ns, > 200mA (Io)

• Reverse Recovery Time (trr):-
• Current - Reverse Leakage @ Vr:40 µA @ 2200 V
• Capacitance @ Vr, F:7pF @ 700V, 1MHz
• Mounting Type:Surface Mount
• Package / Case:TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
• Supplier Device Package:TO-263 (D2Pak-HV)
• Operating Temperature - Junction:-55°C ~ 175°C
