1N5623US

Technical Details

• Series:-
• Package:Bulk
• Part Status:Active
• Diode Type:Standard
• Voltage - DC Reverse (Vr) (Max):1000 V
• Current - Average Rectified (Io):1A
• Voltage - Forward (Vf) (Max) @ If:1.6 V @ 3 A
• Speed:Fast Recovery =< 500ns, > 200mA (Io)

• Reverse Recovery Time (trr):500 ns
• Current - Reverse Leakage @ Vr:500 nA @ 1000 V
• Capacitance @ Vr, F:15pF @ 12V, 1MHz
• Mounting Type:Surface Mount
• Package / Case:SQ-MELF, A
• Supplier Device Package:D-5A
• Operating Temperature - Junction:-65°C ~ 175°C
