VS-85HFLR80S05
Vishay General Semiconductor – Diodes Division
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE GEN PURP 800V 85A DO203AB
- CategoryDiodes - Rectifiers - Single
- Datasheet VS-85HFLR80S05 Datasheet
-
ECAD Model
- Share
In Stock: 185
Can ship immediately
Pricing:
- 1$12.1619
- 100$11.26357
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Diode Type:Standard, Reverse Polarity
- Voltage - DC Reverse (Vr) (Max):800 V
- Current - Average Rectified (Io):85A
- Voltage - Forward (Vf) (Max) @ If:1.75 V @ 266.9 A
- Speed:Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr):500 ns
- Current - Reverse Leakage @ Vr:100 µA @ 800 V
- Capacitance @ Vr, F:-
- Mounting Type:Chassis, Stud Mount
- Package / Case:DO-203AB, DO-5, Stud
- Supplier Device Package:DO-203AB
- Operating Temperature - Junction:-40°C ~ 125°C
