1N6764

Technical Details

• Series:Military, MIL-PRF-19500/642
• Package:Bulk
• Part Status:Active
• Diode Type:Standard
• Voltage - DC Reverse (Vr) (Max):150 V
• Current - Average Rectified (Io):12A (DC)
• Voltage - Forward (Vf) (Max) @ If:1.05 V @ 12 A
• Speed:Fast Recovery =< 500ns, > 200mA (Io)

• Reverse Recovery Time (trr):35 ns
• Current - Reverse Leakage @ Vr:10 µA @ 150 V
• Capacitance @ Vr, F:300pF @ 5V, 1MHz
• Mounting Type:Through Hole
• Package / Case:TO-254-3, TO-254AA
• Supplier Device Package:TO-254
• Operating Temperature - Junction:-55°C ~ 175°C
