R9G01822XX
Powerex, Inc.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE GP 1.8KV 2200A DO200AB
- CategoryDiodes - Rectifiers - Single
- Datasheet R9G01822XX Datasheet
-
ECAD Model
- Share
In Stock: 107
Can ship immediately
Pricing:
- 1$247.245
- 30$240.21004
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Diode Type:Standard
- Voltage - DC Reverse (Vr) (Max):1800 V
- Current - Average Rectified (Io):2200A
- Voltage - Forward (Vf) (Max) @ If:1.1 V @ 1500 A
- Speed:Standard Recovery >500ns, > 200mA (Io)
- Reverse Recovery Time (trr):15 µs
- Current - Reverse Leakage @ Vr:150 mA @ 1800 V
- Capacitance @ Vr, F:-
- Mounting Type:Chassis Mount
- Package / Case:DO-200AB, B-PUK
- Supplier Device Package:DO-200AB, B-PUK
- Operating Temperature - Junction:-
