LLSD101A-7
Zetex Semiconductors (Diodes Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE SCHOTTKY 60V 15MA MINIMELF
- CategoryDiodes - Rectifiers - Single
- Datasheet LLSD101A-7 Datasheet
-
ECAD Model
- Share
In Stock: 179
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- Diode Type:Schottky
- Voltage - DC Reverse (Vr) (Max):60 V
- Current - Average Rectified (Io):15mA (DC)
- Voltage - Forward (Vf) (Max) @ If:1 V @ 15 mA
- Speed:Small Signal =< 200mA (Io), Any Speed
- Reverse Recovery Time (trr):1 ns
- Current - Reverse Leakage @ Vr:200 nA @ 50 V
- Capacitance @ Vr, F:2pF @ 0V, 1MHz
- Mounting Type:Surface Mount
- Package / Case:DO-213AC, MINI-MELF, SOD-80
- Supplier Device Package:Mini MELF
- Operating Temperature - Junction:-55°C ~ 125°C
