1N5820-T
Zetex Semiconductors (Diodes Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE SCHOTTKY 20V 3A DO201AD
- CategoryDiodes - Rectifiers - Single
- Datasheet 1N5820-T Datasheet
-
ECAD Model
- Share
In Stock: 114
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- Diode Type:Schottky
- Voltage - DC Reverse (Vr) (Max):20 V
- Current - Average Rectified (Io):3A
- Voltage - Forward (Vf) (Max) @ If:475 mV @ 3 A
- Speed:Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr):-
- Current - Reverse Leakage @ Vr:2 mA @ 20 V
- Capacitance @ Vr, F:-
- Mounting Type:Through Hole
- Package / Case:DO-201AD, Axial
- Supplier Device Package:DO-201AD
- Operating Temperature - Junction:-65°C ~ 150°C
