VS-8ETH06SPBF

Technical Details

• Series:FRED Pt®
• Package:Tube
• Part Status:Discontinued at Digi-Key
• Diode Type:Standard
• Voltage - DC Reverse (Vr) (Max):600 V
• Current - Average Rectified (Io):8A
• Voltage - Forward (Vf) (Max) @ If:2.4 V @ 8 A
• Speed:Fast Recovery =< 500ns, > 200mA (Io)

• Reverse Recovery Time (trr):25 ns
• Current - Reverse Leakage @ Vr:50 µA @ 600 V
• Capacitance @ Vr, F:-
• Mounting Type:Surface Mount
• Package / Case:TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
• Supplier Device Package:D2PAK
• Operating Temperature - Junction:-65°C ~ 175°C
