BAS29_S00Z

Technical Details

• Series:-
• Package:Tape & Reel (TR)
• Part Status:Obsolete
• Diode Type:Standard
• Voltage - DC Reverse (Vr) (Max):120 V
• Current - Average Rectified (Io):200mA
• Voltage - Forward (Vf) (Max) @ If:1.25 V @ 400 mA
• Speed:Small Signal =< 200mA (Io), Any Speed

• Reverse Recovery Time (trr):50 ns
• Current - Reverse Leakage @ Vr:100 nA @ 90 V
• Capacitance @ Vr, F:2pF @ 0V, 1MHz
• Mounting Type:Surface Mount
• Package / Case:TO-236-3, SC-59, SOT-23-3
• Supplier Device Package:SOT-23-3
• Operating Temperature - Junction:150°C (Max)
