STTH812G

Technical Details

• Series:-
• Package:Tube
• Part Status:Obsolete
• Diode Type:Standard
• Voltage - DC Reverse (Vr) (Max):1200 V
• Current - Average Rectified (Io):8A
• Voltage - Forward (Vf) (Max) @ If:2.2 V @ 8 A
• Speed:Fast Recovery =< 500ns, > 200mA (Io)

• Reverse Recovery Time (trr):100 ns
• Current - Reverse Leakage @ Vr:8 µA @ 1200 V
• Capacitance @ Vr, F:-
• Mounting Type:Surface Mount
• Package / Case:TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
• Supplier Device Package:D2PAK
• Operating Temperature - Junction:175°C (Max)
