MA2Z7480GL
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE SCHOTTKY 20V 300MA SMINI2
- CategoryDiodes - Rectifiers - Single
- Datasheet MA2Z7480GL Datasheet
-
ECAD Model
- Share
In Stock: 185
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- Diode Type:Schottky
- Voltage - DC Reverse (Vr) (Max):20 V
- Current - Average Rectified (Io):300mA
- Voltage - Forward (Vf) (Max) @ If:400 mV @ 300 mA
- Speed:Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr):5 ns
- Current - Reverse Leakage @ Vr:30 µA @ 10 V
- Capacitance @ Vr, F:60pF @ 0V, 1MHz
- Mounting Type:Surface Mount
- Package / Case:SC-90, SOD-323F
- Supplier Device Package:SMini2-F3
- Operating Temperature - Junction:125°C (Max)
