SB120A-E3/73
Vishay General Semiconductor – Diodes Division
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE SCHOTTKY 20V 1A DO204AL
- CategoryDiodes - Rectifiers - Single
- Datasheet SB120A-E3/73 Datasheet
-
ECAD Model
- Share
In Stock: 118
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tape & Box (TB)
- Part Status:Obsolete
- Diode Type:Schottky
- Voltage - DC Reverse (Vr) (Max):20 V
- Current - Average Rectified (Io):1A
- Voltage - Forward (Vf) (Max) @ If:480 mV @ 1 A
- Speed:Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr):-
- Current - Reverse Leakage @ Vr:500 µA @ 20 V
- Capacitance @ Vr, F:-
- Mounting Type:Through Hole
- Package / Case:DO-204AL, DO-41, Axial
- Supplier Device Package:DO-204AL (DO-41)
- Operating Temperature - Junction:-65°C ~ 125°C
