1N5803
Microchip Technology
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE GEN PURP 75V 1A AXIAL
- CategoryDiodes - Rectifiers - Single
- Datasheet 1N5803 Datasheet
-
ECAD Model
- Share
In Stock: 117
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Obsolete
- Diode Type:Standard
- Voltage - DC Reverse (Vr) (Max):75 V
- Current - Average Rectified (Io):1A
- Voltage - Forward (Vf) (Max) @ If:875 mV @ 1 A
- Speed:Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr):25 ns
- Current - Reverse Leakage @ Vr:1 µA @ 75 V
- Capacitance @ Vr, F:25pF @ 10V, 1MHz
- Mounting Type:Through Hole
- Package / Case:A, Axial
- Supplier Device Package:-
- Operating Temperature - Junction:-65°C ~ 175°C
