- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE SCHOTTKY 20A TO-220
- CategoryDiodes - Rectifiers - Single
- Datasheet VS-20TT100 Datasheet
-
ECAD Model
- Share
In Stock: 139
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Diode Type:Schottky
- Voltage - DC Reverse (Vr) (Max):100 V
- Current - Average Rectified (Io):20A
- Voltage - Forward (Vf) (Max) @ If:800 mV @ 20 A
- Speed:Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr):-
- Current - Reverse Leakage @ Vr:150 µA @ 100 V
- Capacitance @ Vr, F:850pF @ 5V, 1MHz
- Mounting Type:Through Hole
- Package / Case:TO-220-2
- Supplier Device Package:TO-220AC
- Operating Temperature - Junction:-55°C ~ 175°C
