JAN1N5814
Microchip Technology
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE GEN PURP 100V 20A DO203AA
- CategoryDiodes - Rectifiers - Single
- Datasheet JAN1N5814 Datasheet
-
ECAD Model
- Share
In Stock: 107
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Discontinued at Digi-Key
- Diode Type:Standard
- Voltage - DC Reverse (Vr) (Max):100 V
- Current - Average Rectified (Io):20A
- Voltage - Forward (Vf) (Max) @ If:950 mV @ 20 A
- Speed:Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr):35 ns
- Current - Reverse Leakage @ Vr:10 µA @ 100 V
- Capacitance @ Vr, F:300pF @ 10V, 1MHz
- Mounting Type:Chassis, Stud Mount
- Package / Case:DO-203AA, DO-4, Stud
- Supplier Device Package:DO-203AA (DO-4)
- Operating Temperature - Junction:-65°C ~ 175°C
