NTS12120EMFST3G
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE SCHOTTKY 120V 12A 5DFN
- CategoryDiodes - Rectifiers - Single
- Datasheet NTS12120EMFST3G Datasheet
-
ECAD Model
- Share
In Stock: 174
Can ship immediately
Pricing:
- 1$0.25732
- 5,000$0.25732
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Obsolete
- Diode Type:Schottky
- Voltage - DC Reverse (Vr) (Max):120 V
- Current - Average Rectified (Io):12A
- Voltage - Forward (Vf) (Max) @ If:830 mV @ 12 A
- Speed:Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr):-
- Current - Reverse Leakage @ Vr:55 µA @ 100 V
- Capacitance @ Vr, F:-
- Mounting Type:Surface Mount
- Package / Case:8-PowerTDFN, 5 Leads
- Supplier Device Package:5-DFN (5x6) (8-SOFL)
- Operating Temperature - Junction:-55°C ~ 150°C
