UFR8520R

Technical Details

• Series:-
• Package:Bulk
• Part Status:Active
• Diode Type:Standard
• Voltage - DC Reverse (Vr) (Max):200 V
• Current - Average Rectified (Io):85A
• Voltage - Forward (Vf) (Max) @ If:975 mV @ 85 A
• Speed:Fast Recovery =< 500ns, > 200mA (Io)

• Reverse Recovery Time (trr):50 ns
• Current - Reverse Leakage @ Vr:50 µA @ 200 V
• Capacitance @ Vr, F:675pF @ 10V, 1MHz
• Mounting Type:Stud Mount
• Package / Case:DO-203AB, DO-5, Stud
• Supplier Device Package:DO-5
• Operating Temperature - Junction:-55°C ~ 175°C
