RA506-BP

Technical Details

• Series:-
• Package:Bulk
• Part Status:Obsolete
• Diode Type:Standard
• Voltage - DC Reverse (Vr) (Max):800 V
• Current - Average Rectified (Io):50A
• Voltage - Forward (Vf) (Max) @ If:1.1 V @ 50 A
• Speed:Standard Recovery >500ns, > 200mA (Io)

• Reverse Recovery Time (trr):3 µs
• Current - Reverse Leakage @ Vr:5 µA @ 800 V
• Capacitance @ Vr, F:300pF @ 4V, 1MHz
• Mounting Type:Surface Mount
• Package / Case:RA
• Supplier Device Package:RA
• Operating Temperature - Junction:-55°C ~ 150°C
