BAT54A-13-F-31

Technical Details

• Series:-
• Package:Tape & Reel (TR)
• Part Status:Obsolete
• Diode Type:Schottky
• Voltage - DC Reverse (Vr) (Max):30 V
• Current - Average Rectified (Io):200mA
• Voltage - Forward (Vf) (Max) @ If:800 mV @ 100 mA
• Speed:Small Signal =< 200mA (Io), Any Speed

• Reverse Recovery Time (trr):5 ns
• Current - Reverse Leakage @ Vr:2 µA @ 25 V
• Capacitance @ Vr, F:10pF @ 1V, 1MHz
• Mounting Type:Surface Mount
• Package / Case:TO-236-3, SC-59, SOT-23-3
• Supplier Device Package:SOT-23
• Operating Temperature - Junction:-65°C ~ 150°C
