MMSZ5249BT1G
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE ZENER 19V 500MW SOD123
- CategoryDiodes - Zener - Single
- Datasheet MMSZ5249BT1G Datasheet
-
ECAD Model
- Share
In Stock: 13,715
Can ship immediately
Pricing:
- 1$0.27
- 3,000$0.03921
- 6,000$0.03429
- 15,000$0.02937
- 30,000$0.02773
- 75,000$0.02609
- 150,000$0.0228
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Voltage - Zener (Nom) (Vz):19 V
- Tolerance:±5%
- Power - Max:500 mW
- Impedance (Max) (Zzt):23 Ohms
- Current - Reverse Leakage @ Vr:100 nA @ 14 V
- Voltage - Forward (Vf) (Max) @ If:900 mV @ 10 mA
- Operating Temperature:-55°C ~ 150°C
- Mounting Type:Surface Mount
- Package / Case:SOD-123
- Supplier Device Package:SOD-123
