SMBJ5936AE3/TR13
Microchip Technology
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE ZENER 30V 2W SMBJ
- CategoryDiodes - Zener - Single
- Datasheet SMBJ5936AE3/TR13 Datasheet
-
ECAD Model
- Share
In Stock: 135
Can ship immediately
Pricing:
- 1$0.611
- 3,000$0.59818
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Active
- Voltage - Zener (Nom) (Vz):30 V
- Tolerance:±10%
- Power - Max:2 W
- Impedance (Max) (Zzt):28 Ohms
- Current - Reverse Leakage @ Vr:1 µA @ 22.8 V
- Voltage - Forward (Vf) (Max) @ If:1.2 V @ 200 mA
- Operating Temperature:-65°C ~ 150°C
- Mounting Type:Surface Mount
- Package / Case:DO-214AA, SMB
- Supplier Device Package:SMBJ (DO-214AA)
