MC78L15ACDG
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC REG LINEAR 15V 100MA 8SOIC
- CategoryPMIC - Voltage Regulators - Linear
- Datasheet MC78L15ACDG Datasheet
-
ECAD Model
- Share
In Stock: 22,763
Can ship immediately
Pricing:
- 1$0.08
- 10$0.06077
- 100$0.03784
- 500$0.02589
- 1,000$0.01991
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Output Configuration:Positive
- Output Type:Fixed
- Number of Regulators:1
- Voltage - Input (Max):35V
- Voltage - Output (Min/Fixed):15V
- Voltage - Output (Max):-
- Voltage Dropout (Max):-
- Current - Output:100mA
- Current - Quiescent (Iq):6.5 mA
- Current - Supply (Max):-
- PSRR:39dB (120Hz)
- Control Features:-
- Protection Features:Over Temperature, Short Circuit
- Operating Temperature:0°C ~ 125°C
- Mounting Type:Surface Mount
- Package / Case:8-SOIC (0.154", 3.90mm Width)
- Supplier Device Package:8-SOIC
