NCP706BMX300TAG
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC REG LINEAR 3V 1A 8XDFN
- CategoryPMIC - Voltage Regulators - Linear
- Datasheet NCP706BMX300TAG Datasheet
-
ECAD Model
- Share
In Stock: 96,149
Can ship immediately
Pricing:
- 1$0.1
- 6,000$0.1
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Obsolete
- Output Configuration:Positive
- Output Type:Fixed
- Number of Regulators:1
- Voltage - Input (Max):5.5V
- Voltage - Output (Min/Fixed):3V
- Voltage - Output (Max):-
- Voltage Dropout (Max):0.23V @ 1A
- Current - Output:1A
- Current - Quiescent (Iq):230 µA
- Current - Supply (Max):-
- PSRR:65dB ~ 52dB (100Hz ~ 10kHz)
- Control Features:Enable
- Protection Features:Over Current, Over Temperature, Soft Start, Under Voltage Lockout (UVLO)
- Operating Temperature:-40°C ~ 125°C
- Mounting Type:Surface Mount
- Package / Case:8-XFDFN Exposed Pad
- Supplier Device Package:8-XDFN (1.6x1.2)
