NX1117C18Z,115
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC REG LINEAR 1.8V 1A SOT223
- CategoryPMIC - Voltage Regulators - Linear
- Datasheet NX1117C18Z,115 Datasheet
-
ECAD Model
- Share
In Stock: 6,043
Can ship immediately
Pricing:
- 1$0.12
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Obsolete
- Output Configuration:Positive
- Output Type:Fixed
- Number of Regulators:1
- Voltage - Input (Max):20V
- Voltage - Output (Min/Fixed):1.8V
- Voltage - Output (Max):-
- Voltage Dropout (Max):1.2V @ 800mA
- Current - Output:1A
- Current - Quiescent (Iq):6 mA
- Current - Supply (Max):-
- PSRR:68dB (120Hz)
- Control Features:-
- Protection Features:Over Current, Over Temperature
- Operating Temperature:-40°C ~ 125°C
- Mounting Type:Surface Mount
- Package / Case:TO-261-4, TO-261AA
- Supplier Device Package:SOT-223
