SP6203ER-L
MaxLinear
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC REG LINEAR POS ADJ 500MA 8DFN
- CategoryPMIC - Voltage Regulators - Linear
- Datasheet SP6203ER-L Datasheet
-
ECAD Model
- Share
In Stock: 101
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Discontinued at Digi-Key
- Output Configuration:Positive
- Output Type:Adjustable
- Number of Regulators:1
- Voltage - Input (Max):6V
- Voltage - Output (Min/Fixed):1.25V
- Voltage - Output (Max):5.2V
- Voltage Dropout (Max):0.5V @ 500mA
- Current - Output:500mA
- Current - Quiescent (Iq):100 µA
- Current - Supply (Max):490 µA
- PSRR:67dB (1kHz)
- Control Features:Current Limit, Enable
- Protection Features:Over Current, Over Temperature
- Operating Temperature:-40°C ~ 125°C (TA)
- Mounting Type:Surface Mount
- Package / Case:8-VFDFN Exposed Pad
- Supplier Device Package:8-DFN (2x3)
