PAM3101FKF380
Zetex Semiconductors (Diodes Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC REG LINEAR 3.8V 300MA 6DFN
- CategoryPMIC - Voltage Regulators - Linear
- Datasheet PAM3101FKF380 Datasheet
-
ECAD Model
- Share
In Stock: 153
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Obsolete
- Output Configuration:Positive
- Output Type:Fixed
- Number of Regulators:1
- Voltage - Input (Max):5.5V
- Voltage - Output (Min/Fixed):3.8V
- Voltage - Output (Max):-
- Voltage Dropout (Max):0.23V @ 300mA
- Current - Output:300mA
- Current - Quiescent (Iq):90 µA
- Current - Supply (Max):90 µA
- PSRR:70dB ~ 65dB (100Hz ~ 1kHz)
- Control Features:Enable
- Protection Features:Over Current, Over Temperature, Short Circuit
- Operating Temperature:-40°C ~ 85°C
- Mounting Type:Surface Mount
- Package / Case:6-WFDFN Exposed Pad
- Supplier Device Package:6-DFN (1.6x1.6)
