AZ78L09Z-G1
Zetex Semiconductors (Diodes Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC REG LINEAR 9V 100MA TO92
- CategoryPMIC - Voltage Regulators - Linear
-
ECAD Model
- Share
In Stock: 140
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Output Configuration:Positive
- Output Type:Fixed
- Number of Regulators:1
- Voltage - Input (Max):18V
- Voltage - Output (Min/Fixed):9V
- Voltage - Output (Max):-
- Voltage Dropout (Max):1.6V @ 40mA (Typ)
- Current - Output:100mA
- Current - Quiescent (Iq):5 mA
- Current - Supply (Max):-
- PSRR:44dB (120Hz)
- Control Features:-
- Protection Features:Over Current, Over Temperature
- Operating Temperature:-40°C ~ 125°C
- Mounting Type:Through Hole
- Package / Case:TO-226-3, TO-92-3 (TO-226AA)
- Supplier Device Package:TO-92
