MAX8559ETAAG+TG50

Technical Details

• Series:-
• Package:Tape & Reel (TR)
• Part Status:Obsolete
• Output Configuration:Positive
• Output Type:Fixed
• Number of Regulators:2
• Voltage - Input (Max):6.5V
• Voltage - Output (Min/Fixed):3.3V, 3V
• Voltage - Output (Max):-
• Voltage Dropout (Max):0.12V @ 100mA, 0.12V @ 100mA

• Current - Output:300mA, 300mA
• Current - Quiescent (Iq):290 µA
• Current - Supply (Max):220 µA
• PSRR:70dB ~ 54dB (10kHz ~ 100kHz)
• Control Features:Enable
• Protection Features:Over Current, Over Temperature, Short Circuit
• Operating Temperature:-40°C ~ 85°C
• Mounting Type:Surface Mount
• Package / Case:8-WDFN Exposed Pad
• Supplier Device Package:8-TDFN-EP (3x3)
