1776702
Phoenix Contact
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTERM BLOCK HDR 3POS 90DEG 5MM
- CategoryTerminal Blocks - Headers, Plugs and Sockets
- Datasheet 1776702 Datasheet
-
ECAD Model
- Share
In Stock: 203
Can ship immediately
Pricing:
- 1$3.02
- 10$2.898
- 50$2.772
- 100$2.6964
- 250$2.52
- 500$2.3184
- 1,000$2.14199
- 2,500$2.0412
- 5,000$1.9152
Quote It
Technical Details
- Series:COMBICON MSTB
- Package:Bulk
- Part Status:Active
- Type:Header, Male Pins, Shrouded (4 Side)
- Number of Positions:3
- Positions Per Level:3
- Number of Levels:1
- Pitch:0.197" (5.00mm)
- Header Orientation:90°, Right Angle
- Plug Wire Entry:-
- Termination Style:Solder
- Mounting Type:Through Hole
- Current - IEC:12A
- Voltage - IEC:400 V
- Current - UL:15 A
- Voltage - UL:300 V
- Wire Gauge or Range - AWG:-
- Wire Gauge or Range - mm²:-
- Color:Green
- Operating Temperature:-
- Contact Mating Finish:Tin
- Features:Mating and Mounting Flange
