ED130/6DS
On-Shore Technology, Inc.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTERM BLOCK PLUG 6POS 90DEG 5MM
- CategoryTerminal Blocks - Headers, Plugs and Sockets
- Datasheet ED130/6DS Datasheet
-
ECAD Model
- Share
In Stock: 327
Can ship immediately
Pricing:
- 1$3.19
- 10$2.411
- 25$2.2344
- 50$2.009
- 100$1.96
- 250$1.715
- 500$1.568
- 1,000$1.421
- 5,000$1.2495
Quote It
Technical Details
- Series:ED130
- Package:Bulk
- Part Status:Active
- Type:Plug for Unshrouded Header
- Number of Positions:6
- Positions Per Level:6
- Number of Levels:1
- Pitch:0.197" (5.00mm)
- Header Orientation:-
- Plug Wire Entry:90°
- Termination Style:Screw
- Mounting Type:Free Hanging (In-Line)
- Current - IEC:-
- Voltage - IEC:-
- Current - UL:10 A
- Voltage - UL:300 V
- Wire Gauge or Range - AWG:14-22 AWG
- Wire Gauge or Range - mm²:1.5mm²
- Color:Blue
- Operating Temperature:-30°C ~ 105°C
- Contact Mating Finish:-
- Features:Interlocking (Side)
