1944340000
Weidmuller
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTERM BLOCK PLUG 3POS STR 5.08MM
- CategoryTerminal Blocks - Headers, Plugs and Sockets
- Datasheet 1944340000 Datasheet
-
ECAD Model
- Share
In Stock: 224
Can ship immediately
Pricing:
- 1$3.86
- 10$2.94254
- 25$2.756
- 50$2.44986
- 100$2.39653
- 250$2.21016
- 500$1.99714
- 1,000$1.7708
- 5,000$1.66428
Quote It
Technical Details
- Series:Omnimate BL
- Package:Bulk
- Part Status:Active
- Type:Plug, Female Sockets
- Number of Positions:3
- Positions Per Level:3
- Number of Levels:1
- Pitch:0.200" (5.08mm)
- Header Orientation:-
- Plug Wire Entry:180°
- Termination Style:Screw - Clamping Yoke (Tension Sleeve)
- Mounting Type:Free Hanging (In-Line)
- Current - IEC:23A
- Voltage - IEC:400 V
- Current - UL:20 A
- Voltage - UL:300 V
- Wire Gauge or Range - AWG:12-30 AWG
- Wire Gauge or Range - mm²:0.2-4mm²
- Color:Black
- Operating Temperature:-50°C ~ 100°C
- Contact Mating Finish:Tin
- Features:Mating Flange, Retention Latches (Non-Wire Side)
