1766291
Phoenix Contact
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTERM BLOCK HDR 8POS 90DEG 7.62MM
- CategoryTerminal Blocks - Headers, Plugs and Sockets
- Datasheet 1766291 Datasheet
-
ECAD Model
- Share
In Stock: 227
Can ship immediately
Pricing:
- 1$4.98
- 10$4.76858
- 50$4.63811
- 100$4.3347
- 250$3.98793
- 500$3.6845
- 1,000$3.51114
- 2,500$3.2944
Quote It
Technical Details
- Series:COMBICON GMSTBA
- Package:Bulk
- Part Status:Active
- Type:Header, Male Pins, Shrouded (4 Side)
- Number of Positions:8
- Positions Per Level:8
- Number of Levels:1
- Pitch:0.300" (7.62mm)
- Header Orientation:90°, Right Angle
- Plug Wire Entry:-
- Termination Style:Solder
- Mounting Type:Through Hole
- Current - IEC:12A
- Voltage - IEC:630 V
- Current - UL:15 A
- Voltage - UL:300 V
- Wire Gauge or Range - AWG:-
- Wire Gauge or Range - mm²:-
- Color:Green
- Operating Temperature:-
- Contact Mating Finish:Tin
- Features:-
