1289480000
Weidmuller
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTERM BLOCK HDR 10POS 90DEG 3.5MM
- CategoryTerminal Blocks - Headers, Plugs and Sockets
- Datasheet 1289480000 Datasheet
-
ECAD Model
- Share
In Stock: 91,582
Can ship immediately
Pricing:
- 1$6.64
- 10$5.05999
- 25$4.73897
- 50$4.21237
- 100$4.12088
- 250$3.80038
- 500$3.43408
- 1,000$3.04488
Quote It
Technical Details
- Series:Omnimate S2C
- Package:Bulk
- Part Status:Active
- Type:Header, Male Pins, Shrouded (4 Side)
- Number of Positions:10
- Positions Per Level:5
- Number of Levels:2
- Pitch:0.138" (3.50mm)
- Header Orientation:90°, Right Angle
- Plug Wire Entry:-
- Termination Style:Solder
- Mounting Type:Through Hole
- Current - IEC:13.4A
- Voltage - IEC:200 V
- Current - UL:10 A
- Voltage - UL:150 V
- Wire Gauge or Range - AWG:-
- Wire Gauge or Range - mm²:-
- Color:Black
- Operating Temperature:-50°C ~ 120°C
- Contact Mating Finish:Tin
- Features:Mating Flange, Solder Retention
