1013150000
Weidmuller
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTERM BLOCK PLUG 8POS STR 5.08MM
- CategoryTerminal Blocks - Headers, Plugs and Sockets
- Datasheet 1013150000 Datasheet
-
ECAD Model
- Share
In Stock: 9,510
Can ship immediately
Pricing:
- 1$8.13
- 10$6.40955
- 36$6.09647
- 72$5.53382
- 108$5.31497
- 252$4.68966
- 504$4.37701
- 1,008$4.06437
Quote It
Technical Details
- Series:Omnimate BL
- Package:Box
- Part Status:Active
- Type:Plug, Female Sockets
- Number of Positions:8
- Positions Per Level:8
- Number of Levels:1
- Pitch:0.200" (5.08mm)
- Header Orientation:-
- Plug Wire Entry:180°
- Termination Style:Screwless - Leg Spring, Push-In Spring
- Mounting Type:Free Hanging (In-Line)
- Current - IEC:24A
- Voltage - IEC:400 V
- Current - UL:18.5 A
- Voltage - UL:300 V
- Wire Gauge or Range - AWG:12-26 AWG
- Wire Gauge or Range - mm²:0.2-2.5mm²
- Color:Orange
- Operating Temperature:-50°C ~ 100°C
- Contact Mating Finish:Tin
- Features:Mating Flange, Retention Latches (Non-Wire Side)
