1065090000
Weidmuller
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTERM BLOCK PLUG 6POS STR 5.08MM
- CategoryTerminal Blocks - Headers, Plugs and Sockets
- Datasheet 1065090000 Datasheet
-
ECAD Model
- Share
In Stock: 183
Can ship immediately
Pricing:
- 1$9.04
- 10$7.73899
- 25$7.38494
- 50$6.63869
- 100$6.28505
- 250$5.69585
- 500$5.30301
- 1,000$5.0084
Quote It
Technical Details
- Series:Omnimate BL
- Package:Box
- Part Status:Active
- Type:Plug, Female Sockets
- Number of Positions:6
- Positions Per Level:6 (Mate), 12 (Input)
- Number of Levels:1 (Mate), 2 (Input)
- Pitch:0.200" (5.08mm)
- Header Orientation:-
- Plug Wire Entry:180°
- Termination Style:Screwless - Leg Spring, Push-In Spring
- Mounting Type:Free Hanging (In-Line)
- Current - IEC:20.8A
- Voltage - IEC:400 V
- Current - UL:10 A
- Voltage - UL:300 V
- Wire Gauge or Range - AWG:12-26 AWG
- Wire Gauge or Range - mm²:0.2-2.5mm²
- Color:Orange
- Operating Temperature:-50°C ~ 100°C
- Contact Mating Finish:Tin
- Features:Mating Flange, Retention Latches (Non-Wire Side)
