1728700000
Weidmuller
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTERM BLOCK HDR 20POS 90DEG 3.5MM
- CategoryTerminal Blocks - Headers, Plugs and Sockets
- Datasheet 1728700000 Datasheet
-
ECAD Model
- Share
In Stock: 7,693
Can ship immediately
Pricing:
- 1$10.54
- 10$9.0286
- 25$8.61621
- 50$7.74559
- 100$7.3331
- 250$6.64562
- 500$6.18728
- 1,000$5.84355
Quote It
Technical Details
- Series:Omnimate S2L
- Package:Bulk
- Part Status:Active
- Type:Header, Male Pins, Shrouded (4 Side)
- Number of Positions:20
- Positions Per Level:10
- Number of Levels:2
- Pitch:0.138" (3.50mm)
- Header Orientation:90°, Right Angle
- Plug Wire Entry:-
- Termination Style:Solder
- Mounting Type:Through Hole
- Current - IEC:10A
- Voltage - IEC:250 V
- Current - UL:10 A
- Voltage - UL:150 V
- Wire Gauge or Range - AWG:-
- Wire Gauge or Range - mm²:-
- Color:Black
- Operating Temperature:-50°C ~ 100°C
- Contact Mating Finish:Tin
- Features:Mating and Mounting Flange
