1612170000
Weidmuller
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTERM BLOCK PLUG 9POS 90DEG 7MM
- CategoryTerminal Blocks - Headers, Plugs and Sockets
-
ECAD Model
- Share
In Stock: 138
Can ship immediately
Pricing:
- 1$17.91
- 10$17.19611
- 25$16.59904
- 50$16.00197
- 100$15.52423
- 250$15.2257
- 500$14.92714
Quote It
Technical Details
- Series:Powermate STV
- Package:Bulk
- Part Status:Active
- Type:Plug, Blade Sockets
- Number of Positions:9
- Positions Per Level:9
- Number of Levels:1
- Pitch:0.276" (7.00mm)
- Header Orientation:-
- Plug Wire Entry:90°
- Termination Style:Screw - Clamping Yoke (Tension Sleeve)
- Mounting Type:Free Hanging (In-Line)
- Current - IEC:32A
- Voltage - IEC:1 kV
- Current - UL:25 A
- Voltage - UL:600 V
- Wire Gauge or Range - AWG:12-22 AWG
- Wire Gauge or Range - mm²:0.5-4mm²
- Color:Gray
- Operating Temperature:-50°C ~ 100°C
- Contact Mating Finish:Silver
- Features:Mating Flange
