1789110000
Weidmuller
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTERM BLOCK PLUG 10/30POS 3.5MM
- CategoryTerminal Blocks - Headers, Plugs and Sockets
- Datasheet 1789110000 Datasheet
-
ECAD Model
- Share
In Stock: 9,579
Can ship immediately
Pricing:
- 1$42.6
- 10$41.0764
- 25$39.55532
- 50$38.94672
- 100$38.03392
- 250$37.27323
Quote It
Technical Details
- Series:Omnimate BL
- Package:Bulk
- Part Status:Active
- Type:Plug, Female Sockets
- Number of Positions:10 (Mate), 30 (Input)
- Positions Per Level:10 (Mate), 30 (Input)
- Number of Levels:1 (Mate), 3 (Input)
- Pitch:0.138" (3.50mm)
- Header Orientation:-
- Plug Wire Entry:180°
- Termination Style:Screwless - Leg Spring, Push-In Spring
- Mounting Type:Free Hanging (In-Line)
- Current - IEC:2.2A
- Voltage - IEC:-
- Current - UL:5 A
- Voltage - UL:50 V
- Wire Gauge or Range - AWG:16-24 AWG
- Wire Gauge or Range - mm²:0.2-1mm²
- Color:Black
- Operating Temperature:-
- Contact Mating Finish:Tin
- Features:LED, Mating Flange
