1580890000
Weidmuller
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTERM BLOCK HDR 5POS 90DEG 5MM
- CategoryTerminal Blocks - Headers, Plugs and Sockets
- Datasheet 1580890000 Datasheet
-
ECAD Model
- Share
In Stock: 554
Can ship immediately
Pricing:
- 1$2.01
- 10$1.52006
- 25$1.40909
- 50$1.26714
- 100$1.23615
- 250$1.08163
- 500$0.98892
- 1,000$0.89621
- 5,000$0.78805
Quote It
Technical Details
- Series:Omnimate SL
- Package:Bulk
- Part Status:Active
- Type:Header, Male Pins, Shrouded (4 Side)
- Number of Positions:5
- Positions Per Level:5
- Number of Levels:1
- Pitch:0.197" (5.00mm)
- Header Orientation:90°, Right Angle
- Plug Wire Entry:-
- Termination Style:Solder
- Mounting Type:Through Hole
- Current - IEC:18A
- Voltage - IEC:400 V
- Current - UL:15 A
- Voltage - UL:300 V
- Wire Gauge or Range - AWG:-
- Wire Gauge or Range - mm²:-
- Color:Orange
- Operating Temperature:-50°C ~ 100°C
- Contact Mating Finish:Tin
- Features:-
