284541-8
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTERM BLOCK HDR 8POS 90DEG 3.81MM
- CategoryTerminal Blocks - Headers, Plugs and Sockets
- Datasheet 284541-8 Datasheet
-
ECAD Model
- Share
In Stock: 254
Can ship immediately
Pricing:
- 1$4.89
- 10$3.725
- 25$3.4888
- 50$3.1012
- 100$3.0337
- 250$2.79776
- 500$2.5281
- 1,000$2.24158
Quote It
Technical Details
- Series:Buchanan
- Package:Bulk
- Part Status:Active
- Type:Header, Male Pins, Shrouded (4 Side)
- Number of Positions:8
- Positions Per Level:8
- Number of Levels:1
- Pitch:0.150" (3.81mm)
- Header Orientation:90°, Right Angle
- Plug Wire Entry:-
- Termination Style:Solder
- Mounting Type:Through Hole
- Current - IEC:-
- Voltage - IEC:-
- Current - UL:11 A
- Voltage - UL:300 V
- Wire Gauge or Range - AWG:-
- Wire Gauge or Range - mm²:-
- Color:Green
- Operating Temperature:-40°C ~ 110°C
- Contact Mating Finish:Tin
- Features:Mating Flange
