1946330000
Weidmuller
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTERM BLOCK PLUG 10POS 5.08MM
- CategoryTerminal Blocks - Headers, Plugs and Sockets
- Datasheet 1946330000 Datasheet
-
ECAD Model
- Share
In Stock: 178
Can ship immediately
Pricing:
- 1$9.73
- 10$8.33701
- 25$7.95619
- 50$7.15202
- 100$6.7712
- 250$6.13637
- 500$5.71318
- 1,000$5.39577
Quote It
Technical Details
- Series:Omnimate BL
- Package:Bulk
- Part Status:Active
- Type:Plug, Female Sockets
- Number of Positions:10
- Positions Per Level:10
- Number of Levels:1
- Pitch:0.200" (5.08mm)
- Header Orientation:-
- Plug Wire Entry:225°
- Termination Style:Screw - Clamping Yoke (Tension Sleeve)
- Mounting Type:Free Hanging (In-Line)
- Current - IEC:17.5A
- Voltage - IEC:400 V
- Current - UL:15 A
- Voltage - UL:300 V
- Wire Gauge or Range - AWG:12-30 AWG
- Wire Gauge or Range - mm²:0.2-4mm²
- Color:Orange
- Operating Temperature:-50°C ~ 100°C
- Contact Mating Finish:Tin
- Features:Retention Latches (Non-Wire Side)
