TBP01P1W-508-08BE
CUI Devices
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTERMINAL BLOCK, PLUGGABLE, W SCR
- CategoryTerminal Blocks - Headers, Plugs and Sockets
-
ECAD Model
- Share
In Stock: 426
Can ship immediately
Pricing:
- 1$2.18
Quote It
Technical Details
- Series:TBP01P1W-508
- Package:Bag
- Part Status:Active
- Type:Plug, Female Sockets
- Number of Positions:8
- Positions Per Level:8
- Number of Levels:1
- Pitch:0.200" (5.08mm)
- Header Orientation:-
- Plug Wire Entry:180°
- Termination Style:Screw - Rising Cage Clamp
- Mounting Type:Free Hanging (In-Line)
- Current - IEC:20A
- Voltage - IEC:320 V
- Current - UL:16 A
- Voltage - UL:300 V
- Wire Gauge or Range - AWG:12-28 AWG
- Wire Gauge or Range - mm²:2.5mm²
- Color:Blue
- Operating Temperature:-40°C ~ 105°C
- Contact Mating Finish:Nickel
- Features:Mating Flange, Retention Latches (Non-Wire Side)
