1777303
Phoenix Contact
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTERM BLOCK PLUG 4POS STR 5.08MM
- CategoryTerminal Blocks - Headers, Plugs and Sockets
- Datasheet 1777303 Datasheet
-
ECAD Model
- Share
In Stock: 154
Can ship immediately
Pricing:
- 1$10.8
- 10$10.505
- 50$9.8176
- 100$9.0321
- 250$8.34492
- 500$7.95216
- 1,000$7.46132
Quote It
Technical Details
- Series:COMBICON FRONT-MSTB
- Package:Bulk
- Part Status:Active
- Type:Plug, Female Sockets
- Number of Positions:4
- Positions Per Level:4
- Number of Levels:1
- Pitch:0.200" (5.08mm)
- Header Orientation:-
- Plug Wire Entry:180°
- Termination Style:Screw - Pressure Clip
- Mounting Type:Free Hanging (In-Line)
- Current - IEC:12A
- Voltage - IEC:630 V
- Current - UL:15 A
- Voltage - UL:300 V
- Wire Gauge or Range - AWG:12-30 AWG
- Wire Gauge or Range - mm²:0.2-2.5mm²
- Color:Green
- Operating Temperature:-
- Contact Mating Finish:Tin
- Features:Retention Latches (Non-Wire Side)
