1289300000
Weidmuller
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTERM BLOCK HDR 12POS 90DEG 3.5MM
- CategoryTerminal Blocks - Headers, Plugs and Sockets
- Datasheet 1289300000 Datasheet
-
ECAD Model
- Share
In Stock: 110
Can ship immediately
Pricing:
- 1$6.56
- 10$4.99964
- 25$4.68254
- 50$4.16235
- 100$4.07192
- 250$3.75517
- 500$3.39324
- 1,000$3.00866
Quote It
Technical Details
- Series:Omnimate S2C
- Package:Bulk
- Part Status:Active
- Type:Header, Male Pins, Shrouded (4 Side)
- Number of Positions:12
- Positions Per Level:6
- Number of Levels:2
- Pitch:0.138" (3.50mm)
- Header Orientation:90°, Right Angle
- Plug Wire Entry:-
- Termination Style:Solder
- Mounting Type:Through Hole
- Current - IEC:13.4A
- Voltage - IEC:200 V
- Current - UL:10 A
- Voltage - UL:150 V
- Wire Gauge or Range - AWG:-
- Wire Gauge or Range - mm²:-
- Color:Black
- Operating Temperature:-50°C ~ 120°C
- Contact Mating Finish:Tin
- Features:-
